Chapter 1 Overview
7
Specifications of SMT7 Controller (2)
Item Specifications
Motor cable, encoder cable
(option)
4 m, 6 m, 12 m
(Connected to the controller via the branch cable.)
I/O cable (option)
8 m, 15 m
(For Mini I/O, HAND I/O, Optional board for parallel I/O and SAFETY I/O)
Cables
Power supply cable
5 m
Environmental conditions
(in operation)
Temperature: 0 to 40C
Humidity: 90% RH or less (no condensation allowed)
Power source
（at full IPM boards）
Three-phase, 200 VAC-15% to 230 VAC+10%, 50/60 Hz, 3.3KVA
Single-phase, 230 VAC-10% to 230 VAC+10%, 50/60 Hz, 3.3KVA
External power source
A 24 VDC ±10% should be
supplied from external equipment.
I/O
power
source
Internal power source
A 24 VDC ±10% should be
supplied internally in the
controller.
Note: Refer to the RC7M
CONTROLLER MANUAL, sections
4.2.1 and 5.2.1 "Setting up Mini I/O
Power Supply."
Safety category
With safety board: Compliant with safety category 3
With safety box: Compliant with safety category 4
Degree of protection
IP20
Weight (at full IPM boards)
Approx. 22 kg (49 lbs)
Controller Handling Notes
WARNING
DO NOT touch fins. Their hot surfaces may cause severe burns.
DO NOT insert fingers or foreign objects into openings. Doing so may cause
bodily injury.
Before opening the controller cover and accessing the inside of the controller
for maintenance, be sure to turn off the power switch, disconnect the power
cable, and wait 3 minutes or more. This is for protecting you from electric
shock.
DO NOT connect or disconnect connectors to/from the controller when the AC
power or the 24 VDC power for I/O is being supplied. Doing so may cause
electric shock or controller failure.
CAUTION IN INSTALLATION
This controller is not designed to be dust-proof, splash-proof, or
explosion-proof.
Read operation manuals before installation.
Do not place anything on the controller.
CAUTION
The controller connectors are of a screw-lock type or ring-lock type. Lock the
connectors securely. If even one of the connectors is not locked, weak contact
may result thereby causing an error.
Be sure to turn the controller OFF before connecting/ disconnecting the power
connector or motor connector. Otherwise, the internal circuits of the controller
may be damaged.
