Chapter 1 Overview
10
"THE SETPRM LIST" of the SMT7
The SMT7 is customized for motors specified by each customer in both hardware
and software at the factory. The allowable combination of the controller's axes and
motor types is printed in (2) SUBASSEMBLY on the "THE SETPRM LIST" labeled on
the top of the controller.
According to the allowable combination, connect motors to the controller correctly.
Incorrect connection will result in a motor malfunction, controller overheat, motor
overheat, and other problems.
Note: When shipped from the factory, IPM boards suited to AC servomotors to be connected will
be built into the controller for 1 to 6 axes.
Motor capacity 50 W 100 W 200 W 400 W 750 W 1.5 kW
IPM board type SS SS S S M LL
SETPRM LIST
