Derby cycle Pedelec - Page 7

Originalbetriebsanleitung Allgemein EN-7
Trekking Bike
This is a sample illustration of our bicycles.
1 Front stem
2 Handlebar grip
3 Bell
4 Handlebars
5 Headset
6 Head tube
7 Spotlight
8 Mudguard
9 Fork
10 Tyre
11 Brake disc
12 Front wheel hub
13 Rims
14 Spokes
15 Front brake
16 Wheels
17 Pedals
18 Crank
19 Belt
20 Sprocket
21 Rear wheel hub
22 Stand
23 Rear light
24 Reector
25 Luggage rack
26 Saddle
27 Seat post
28 Saddle clamp
29 Seat tube
30 Crossbar
31 Down tube
