TECHNICAL REFERENCE MANUAL 


4.13.1. MINITAURs: Specifications 
Analog inputs 
Inputs 
8 ch voltage 
Full / Half / Quarter bridge strain 
ADC type 
24-bit delta-sigma DUALCOREADC® with anti-aliasing filter 
Sampling rate 
Simultaneous 200 kS/sec 
DUALCOREADC® Ranges (Low Range) 
±10 V (500 mV), ±1 V (50 mV), ±100 mV (5 mV), ±10 mV (0.5 mV) 
Bridge ranges @ 10 Vexc (Low Range) 
1000 (50) mV/V, 100 (5) mV/V, 10 (0.5) mV/V, 1 (0.05) mV/V 
Dynamic Range @ 10 kS (DUALCOREADC®) 
137 dB (152 dB) 
Input coupling 
DC 
Input impedance 
10 MΩ 
Bridge modes 
Full / Half / Quarter Br 120 / 350 Ω 3-wire; internal bridge 
completion 
Internal shunt resistor 
100 kΩ, bipolar to Exc+ or Exc- (others on request) 
TEDS 
Standard + DSI adapters 
Excitation Voltage 
0 to 12 VDC software programmable (16-bit DAC), max 44 mA 
Overvoltage protection 
In+ to In-: 50 V continuous; 200 V peak (10 msec) 
Digital inputs 
Inputs 
8 counter 
24 digital 
Fully synchronised with analog data 
Input level compatibility 
CMOS, LVTTL 
Input protection 
±25 V continuous 
Digital output 
8 ch open collector, max. 100 mA / 30 V 
CAN bus 
Inputs 
1 CAN port 
CAN port type 
CAN 2.0B full speed, read&write 
Computer 
Processor 
Intel® Core™ i3 
2x 2.1 GHz base 
4 threads 
Memory 
4 GB (up to 16 GB upon request) 
Storage 
250 GB removable SATA SSD 
Option: 1 TB removable SATA SSD 
Option: 250 GB mSATA internal SSD 
Interfaces and options 
