TECHNICAL REFERENCE MANUAL 


4.10.4. SIRIUS-R4-HUB: Specification 
Interfaces and options 
USB Front 
1x USB 2.0, USB Mini B 
Synchronisation 
2x SIRIUS® SYNC 
USB 2.0 hub 
Bandwidth 
Minimum 20 MB/sec 
Typical 25 MB/sec 
Maximum 28 MB/sec 
SIRIUS Dual Core 
32 AI Channels at 200 kS/sec @ 25.6 MB/sec 
SIRIUS HS 
32 AI Channels, 450 kS/sec @ 28.8 MB/sec 
8 AI Channels + 1 Counter, 1000 kS/sec @ 20 MB/sec 
Power 
Power supply 
9 - 36 V DC 
Connector 
3-pin LEMO male 
Power consumption 
Typ. 4.8 W (Max. 6.8 W) 
(excl. SIRIUS® slices) 
R4rt optional EtherCAT® slave port 
Minimum delay (analog input to EtherCAT® bus) 
70 µs 
Minimum EtherCAT® cycle time 
100 µs 
Environmental 
Operating Temperature 
-10 to 50°C 
Storage Temperature 
-40 to 85°C 
Humidity 
95 % RH non condensing @ 50°C 
IP rating 
IP20 
Shock & Vibration 
Vibration sweep sinus (EN 60068-2-6:2008)\ 
Vibration random (EN 60721-3-2: 1997 - Class 2M2) 
Shock (EN 60068-2-27:2009) 
MIL-STD-810D 
Physical 
Dimensions 
276 x 251 x 150 mm 
Weight 
2.75 kg (excl. SIRIUS® slices) 

 
