SIRIUS

® 

TECHNICAL REFERENCE MANUAL 



4.5.1. SIRIUS-SBOXe/fe: Speciﬁcations 

The SIRIUS-SBOXe version is an SBOX with EtherCAT® interface. It is available in the Modular Solution                

and also in the Boxed Solution. 



SBOXe 

SBOXfe 

Computer 

Processor 

Intel® Core™ i7 

4x 2.0G Hz base, 2.8 GHz max 

8 threads 

Intel® Core™ i7 

2x 1.7 GHz base, 2.8 GHz max 

4 threads 

Memory 

8 GB (optional up to 32 GB) 

8 GB (optional up to 16 GB) 

Storage 

500 GB removable SATA SSD 

Option: 1 TB removable SATA SSD 

Option: 250 GB mSATA internal SSD 

Interfaces and options 

USB 

Front: 4x USB 3.0, Rear: 2x USB 2.0 

Ethernet 

2x GLAN, 1x WLAN 

EtherCAT® 

1x EtherCAT® 100 Mbps Full Duplex, 8-pin LEMO female 

Synchronisation 

1x SIRIUS® SYNC 

Video 

1x DVI (VGA and HDMI compatible) 

GPS (option) 

10 Hz, 100 Hz, 100 Hz & RTK 

GPS display (option) 

External on DSUB-9 female connector with remote power on 

Power out 

Switched input supply on 2-pin LEMO female (max. 8 A) 

Power 

Power supply voltage 

9 - 36 V DC 

Power consumption 

Typ. 40 W (Max. 55 W) 

30 W Max. 

Environmental 

Operating temperature 

-10 to 50 °C 

Storage temperature 

-20 to 80 °C 

Humidity 

5 to 95 % RH non-condensing at 50 °C 

IP rating 

IP20 

IP50 

Shock & Vibration 

Vibration sweep sinus (EN 60068-2-6:2008) 

Vibration random (EN 60721-3-2: 1997 - Class 2M2) 

Shock (EN 60068-2-27:2009) 

MIL-STD-810D 

Physical 

Dimensions 

265 x 150 x 75 mm 

265 x 150 x 80 mm 

Weight 

2.1 kg 

2.4 kg 

SIRIUS

V20-1 56 / 336  
