TECHNICAL REFERENCE MANUAL 


4.8.3. SIRIUS-R2DB: Specifications 
Display 
Type 
12.1'' TFT 
Touch Screen 
PCAP, Multi-touch 
Resolution 
WXGA, 1280 x 800 pixels @ 60 Hz 
Brightness 
700 cd/m² 
Batteries 
Battery type 
NL2024HD 
Number of batteries 
2, hot swappable 
Voltage 
14.4 V (at fully charged state 16.8 V) 
Total capacity of single battery 
6.25 Ah 
Discharge current of single battery 
8 A 
Wrong polarity protection 
YES 
Weight of single battery 
0.65 kg 
Power 
Power Supply 
9 - 36 V DC 
Power Consumption 
Max. 30 W (Display & Computer) 
Power out 
Type 
Switched input supply on 2-pin LEMO female 
Maximum power 
60 W 
Output Voltage 
13 - 16 V without external supply, 24 V with external supply 
EtherCAT® Power out 
Type 
Switched input supply on EtherCAT® connector, 8-pin LEMO 
female 
Maximum power 
40 W 
Output Voltage 
13 - 16 V without external supply, 24 V with external supply 
Environmental 
Operating Temperature 
0 to 40°C 
Storage Temperature 
-20 to 60°C 
Humidity 
5 to 95 % RH non-condensing at 40 °C 
IP rating 
IP20 
Shock & Vibration 
Vibration sweep sinus (EN 60068-2-6:2008)\ 
Vibration random (EN 60721-3-2: 1997 - Class 2M2) 
Shock (EN 60068-2-27:2009) 
MIL-STD-810D 
Physical 
Dimensions 
332 x 225 x 194 mm 
Weight 
7.8 kg (excl. SIRIUS® slices) 
11 kg (std. system, with batteries) 
Hint 
A version without battery is also available (R2D). The specifications of SIRIUS-R2D are identical to               
SIRIUS-R2DB, except that SIRIUS-R2D does not have an integrated BMS (Battery Management            
System). 
