SIRIUS
®
TECHNICAL REFERENCE MANUAL
2 mV/V…1000 mV/V free programmable with Dual Core
Internal Bridge
Completion
½ bridge 1 kΩ and ¼ bridge 120 Ω and 350 Ω
Typ. Bridge Completion
Accuracy
0.05 %; TCR: 5 ppm/K (others on request)
Internal Shunt Resistor
59.88 kΩ, software selectable (others on request)
Typ. Shunt Resistor
Accuracy
0.05 %; TCR: 10 ppm/K (others on request)
Input Short, Sensor
Offset Adjust
1 digital counter input
3 digital inputs
Fully synchronised with analog data
counting, waveform timing, encoder, tacho, gear-tooth sensor
Input Level Compatibility
CMOS, LVTTL (protected up to ±25 Volt continuous)
1 channel, 24-bit sigma delta 200 kHz, ±10 V
±0.1 % of reading ±0.02 V
±50 ppm/K of reading ± 200 µV/K
Maximum Output
Current / Load
Continuous short to ground
Additional Specifications
DSUB-15, 16-pin LEMO-2B (others on request)
Standard + DSI® adapters
SIRIUS
®
V20-1 166 / 336
