● Replaced R2D with R2DB
● Corrected the Power connector types
● Corrected image of SBOXf backside-connectors
● Removed 20Hz GPS option
● Removed old documentation history entries (pre 1.3.0) from this
table
● Added R8DB, R2D, SBOXre
● changes: SBOX2→SBOXe, FLASH120→FLASH250,
SIRIUSf-SBOX→SBOXfe, Single slice→Modular solution,
Mulit‐slice→Boxed Solution
● Updated specifications of all SBOXes
● Updated specifications to HS‐LVv2 and HS_HVv2, HD-STGS
(dynamic Range)
● Counter modules:
○ added chapter “General Counter Specifications” and
clarification of the GND connection
○ updated images
● Added “R2DB Power-Out Specifications”, pinning table for 5.13.5 STG
DSUB‐9, description for “Module” in chapter 5.2 Technology
overview,
● table with GPS specifications, MIL‐STD‐810D to Specifications,
chapter “HS-STG: Sensor connection”
● Added Mating Connector info to STG‐L2B7f, STG‐L2B10f and
HD-STGS L1B10f
● Update STGM to STGMv3 (Excitation Voltage: Predefined levels)
● Updated STGv2 to STGv3:
○ Updated Typ. CMR
○ Max. common mode voltage
● Updated ACC to ACCv2 (IEPE mode Excitation)
○ Updated: Offset drift, Channel cross talk, Input coupling,
Input Impedance
● Updated HS-LV Input Impedance
● HD-LV: added max. common mode voltage
● HD-STGS: Max. common mode voltage
● Corrected ADC link in specs of: HS-HV, HS-LV, HS-STG
● HS-STG: update: offset drift, Max. common mode voltage, Offset
accuracy after Balance Amplifier, Input accuracy
