MCQ-PRO RFID Reader — Installation and Tuning Manual Version 1.00
Page 43 of 89
Select the power to emit in milliwatts.
Channel Status:
Select the channel whose status should be displayed. This allows monitoring physical
parameters of the channel and detecting potential issues.
If a critical issue happens, a warning icon will appear beside the parameter.
When RF is turned on, device’s radio uses default RF configuration.
You need to turn RF on before performing any RFID operation such as starting a
default read (see section 8) or sending commands to tags (see section 9).
To turn RF on or off, click or button in the toolbar.
CAUTION: Make sure antennas are connected to channels you use before
turning the radio field on; otherwise it may severely damage the device.
DC Injection:
Enable this feature to add a DC component on the RF signal in order to power up an external
device through the RF cable.
7.1.2 Multiplexer Configuration
Multiplexer is used to program a sequence of channel activation to use during default read
(see section 8 for more information).
To use multiplexer configuration during default read, you must enable the
multiplexer read mode. See section 8.2.4 for more information.
Multiplexer cannot be used for sending commands to tags.
