F/5
- ATTENTION: - Read the SAFETY REGULATIONS (contained in this manual) carefully for the safety of all personnel and your vehicle.
1. Oil tank 2. Pump 3. Distributor 4. Boom raising cylinder 5. Simple effect lock valve 6. Heat exchanger 7. Quick couplings 8. Internal extensoin cylinder 9. Compensation cylinder 10. Swivel cylinder 11. One-way valve 12. Unidirectional valve 13. Double effect lock valve 14. One-way valve 15. Power steering 16. Steering selection valve 17. Negative brake engagement valve 18. Hydrostatic drive 19. Priority valve 20. Oil lter 21. Inching valve
HYDRAULIC PLANT KEY
APOLLO
A - PUMP B - ENGINE C - NEGATIVE BRAKE D - FRONT STEERING E - REAR STEERING F - ACCESSORY G - SWIVEL H - LIFTING I - INTERNAL EXTENSION
