Figure 15: Synchronized Blasting via Multiple Commanders
a. Repeat steps a – d as specified for remote blasting.
b. When configuring the base and selecting the bench commanders to be blasted, select the sync option
c. A sync-management period will automatically be applied at step l to ensure 1ms synchronization between
Commanders.
ARM AND FIRE COMMANDS FOR DETONATORS WILL NOT INITIALLY BE KNOWN TO THE DIGISHOT
®
PLUS
4G COMMANDER. THESE COMMANDS ARE ONLY AVAILABLE FROM THE BLASTCARD (RED) AND WILL BE
ISSUED TO THE COMMANDER WHEN NECESSARY, EITHER DIRECTLY FROM THE BLASTCARD (IN CASE OF A
LOCAL BLAST) OR REMOTELY FROM THE BASE COMMANDER. ARM AND FIRE BLASTING COMMANDS WILL
BE ERASED FROM THE COMMANDER MEMORY AFTER USE.
