System Limits define the design parameters that users must adhere to when designing their blast to be used with
DigiShot
®
Plus 4G Commander System.
Maximum harness wire per channel
2,500m
Maximum accumulated down-line wire per channel
16 000m
Maximum Bench Commanders per Base Commander
10
Maximum detonators per Tagger
16000
Maximum detonators per Channel
400
Maximum detonators per Bench Commander
1600
Maximum detonators RF
16000
Maximum detonators standalone
1600
Maximum detonators per hole
18
Maximum holes per String
400
Maximum ViewShot designs per Tagger
10
Maximum line-of-sight for Remote Firing
3km
Maximum delay for any detonator
20,000ms
Minimum delay per detonator
0ms
Minimum delay increment
1ms
Maximum Wi-Fi connectivity distance
10m
Maximum Distance using Repeater
6km
Maximum Tagger ID’s
10
Maximum Commander ID’s
10
• User selectable 1 – 40 Strings. (Only 1 string can be connected and tested by the Tagger at a time
(assuming the total dets is more than channel capacity)
• 400 Detonators using down-line wire of 40m or lower.
• For longer lengths, see “Wire calculation table under Product Documents on DetNet Portal of down-line
length versus amount of DigiShot
®
Plus 4G Detonators.
• 16000 Detonators in storage/memory
• The Tagger can physically test only 400 dets (one String) at a time.
• 18 Detonators per hole with 6 decks and 3 detonators per deck.
• 10 meters
• -30°C to +60°C / -22°F to +140°F.
• Cold Temperature Battery Pack can be used to extend battery operating life in sub-zero conditions.
