Harness wire terminals
Pogo Pin Connector
Blue Status LED
White Charge LED
Red Error LED
LCD Screen
SoftKeys
Navigation keys (yellow arrows)
Enter key
Backspace key
Escape key
On/Off key
Numerical keys
USB connector
Figure 5: CE4 Tagger Component Identification
