Table 3: CE4 Tagger Menu Reference
Info Screen
Main Menu
Configuration
Regulatory Info
1. New design
1. 4G Setup
Battery/Current/Cell
Status/Temp/Humidity
2. Tag detonators
2. Device Setup
HW serial no/SW
release/Service date
3. Test menu
3. Advanced Setup
GPS data/Satellites/Altitude
4. View design
4. Factory Setup
User ID
5. Mark detonators
5. DGPS Setup
6. Assign ViewShot - Available in
Planned (P) tagging option only
7. ViewShot - Available in
Planned (P) tagging option only
Table 4: CE4 Tagger Main Menu Reference
1-New Design
Warning Displayed: Do you want to clear the list? Y/N
Main Menu is presented. This will clear the tagged detonator list and
not the ViewShot design
(Planned mode) Warning Displayed: Selected Plan xx
Only connect one detonator at a time
2 -Tag detonators
Warning Displayed:
• Selected Plan xx. Connect one det at a time
• If No plan available. Use ViewShot 3D to download a plan!
Tagging detail settings
3-Test Menu
3.1. Test All
3.2. Test String
3.3. Test Single Det
3.4. Leakage Test
3.5. Untagged Test
3.6. Search Dets
4-View Design/Plan
4.1. List Detonators
4.2. List Missing Dets
4.3. List New Dets
4.4. List Bad Status
4.5. Duplicate Location
4.6- Blast Summary
5-Mark Detonators
5.1. End of Line
5.2. Start of Row
