Figure 6: CE4 Tagger External Battery Pack
The Top Connector contains the pogo pins, used for tagging the detonators (one detonator at a time)
It also consists of the Harness wire terminals, used to connect to the detonator harness wire (multiple detonators
on the same wire bus).
Figure 7: CE4 Tagger Top Connector
The Top Connector may be ordered separately and is easily replaceable should the contacts become worn and/or
damaged, through prolonged use.
