UTM-00339 | Rev 19
Page 46 of 253
DetNet South Africa Copyright © 2021
The External Battery Pack is an optional accessory used to increase the capacity of the internal battery when
operating in sub-zero temperatures or other environments that demand extended operating times.
The Internal Heater Pad can operate with the internal polymer battery, independently of the external battery pack,
and will switch ON when the temperature drops below -15°C.
External Battery Pack enclosure is attached to the back of the CE4 Tagger
by four retaining screws.
Six batteries are fitted in the bottom of the External Battery Pack. A
cover closes the battery bay.
Replace using 6 x 1.5V AA Alkaline or 6 x 1.2V Ni-MH / Ni-Cd batteries only.
The battery life will decrease with extended use of heater pad at temperatures below 15°C.
The CE4 control equipmet should not be exposed to severe cold tempertaures when not in
use.
