DIGISYNTHETIC K3 - Microphone PEQ Settings; Microphone Direct Sound Volume, Phase Settings

10
7.8 microphone PEQ settings
Balanced qty: 10
Type: parametric equalization filter (can be set to low / treble tone filter), graphic equalizer
Frequency range: 20hz ~ 20khz
Gain Range:-15db ~ +12 db (can be limited to +6db settings, setting from Device Settings
in the interface software), step 0.1db
Bandwidth range: 0.011 to 3.595
operation: (panel only set the gain of equalizer election) Press the panel button microphone mode
until show MIC PEQ as below:
" "
" "
Buttons "<" and ">" to select the desired setting PEQ
Turning knob music volume / edit (press) to set the gain
Operating method 2: Operation from the interface software
to set up(all equalizer parameters can be set)
7.9 microphone direct sound volume, phase settings
Volume range: 0% ~100%, Stepping: 1%
Phase range: 0 180
Operation method 1: Press the panel button microphone mode " continuously into the microphone menu,
selected the direct sound and phase, as shown below:
° °
"
Keys "<" and ">" to switch direct sound and phase.
Turning knob "usic volume / edit (press) "to set
Operating method 2: Operation from the interface software to set up
MIC PEQ1 80.3Hz
+ 5.9
+ 6
- 6
100%
[0 ]
MIC DIR VOL
PHASE
Panel
Panel
Display
Panel
Panel
Display
