13
ECHO MODE
MONO
ECHO TO REV OFF
7.16 Echo mode, Echo thickness settings
Range: Single, stereo, dual echo
Range: On, Off
Operation: Press the buttons "Effect Mode" on the panel continuously into the Echo Mode/ Echo Thickness,
as shown below:
Keys "<" and ">" Switch echo pattern and thickness.
Turning knob "music volume / edit (press) "to set
Operating method 2: operation from the interface software to set up
7.17 Reverb volume, phase settings
Volume range: mute,-30db ~ 0db, Stepping: 0.5db
Phase range: 0 , 180
Operation: Press the buttons "Effect Mode" on the panel continuously into the Reverb
Volume/ Phase, as shown below:
Keys "<" and ">" switch reverb volume and phase.
Turning knob "music volume / edit (press) "to set
Operating method 2: Operation from the interface software to set up
7.18 reverb pre-delay, reverb-time setting
Reverb pre-delay range :0-250ms, Stepping: 10ms
Reverb-time range :0.5-6s, Stepping: 0.1s
Operation: Press the buttons "Effect Mode" on the panel continuously into the Reverb
Pre-delay/ Reverb-time, as shown below
Keys "<" and ">" switch reverb pre-delay and reverb-Time.
Turning knob "music volume / edit (press) "to set
Operating method 2: Operation from the interface software to set up
:
° °
REV PRE-DELAY 0ms
REV TIME 3.2s
Panel
Display
Panel
Panel
10.0dB－
[0 ]
Display
REV VOL
PHASE
Panel
Panel
Panel
Display
