iPB-10 Rear PaneliPB-10 Rear Panel
1/4” Line Outputs
These 1/4” outputs can be plugged
into a guitar amplier or to the inputs
of a mixer or recording device.
Output Level
This knob controls the output
level of the 1/4” outputs.
Amp/Mixer Switch
This switch opmizes the 1/4”
line outputs for connecng to
either a guitar amp or directly
into the inputs of a mixer.
XLR Ground Lift Switch
This switch lis pin 1 – of the
XLR mixer outputs – from
all ground references. This
may be necessary to help
solve troublesome ground
loops that can cause hum in
the system, especially when
both XLR and 1/4” outputs
are used together.
XLR Mixer Outputs
The XLR outputs are designed for
connecng to a recording device or
mixing console. These outputs always
have speaker compensaon acve as
they are intended to be connected to
a full range audio system.
