Service - 88 C16x/C24x/C30x Operator’s Manual
Each Use
Check Hydraulic Fluid Level
Check hydraulic fluid level before each use.
1. Ensure digging boom is fully raised.
2. Check hydraulic fluid at sight glass (1).
3. If low, add appropriate fluid until fluid level is
at mid-level in sight glass.
4. To clean dust from cap (2), blow with low
pressure air.
Check Hydraulic Fluid Cooler
Check hydraulic fluid cooler before each use.
1. Check hydraulic fluid cooler.
2. If dirty, blow with low pressure air.
3. For extensive cleaning, remove grill.
Contents under pressure. Relieve pressure before
opening. Death or injury could occur.
To help avoid injury:
• Wear gloves and safety glasses.
• Wait until cool to decrease pressure in hydraulic reservoir.
• To release remaining pressure, slowly open hydraulic reservoir.
