Quick configuration wizard
Selection of
automation type
Selection of the
direction mode
30-5 command
operation mode
Automatic closure
enabling
Automatic
closing time
Selection of device
connected to terminals
1-6
Selection of device
connected to terminals
1-8
Configuration of input 30-9
Radio receiver
operation
Setting of radio encrypted
AES-128 messages
Remote control
storage
Confirm
configuration
7.3 Menu map
Selection of
automation type
Selection of the
direction mode
Resetting of factory
settings
Activation
of advanced
parameters menu
Residential 0
Residential 1
Condominium 0
Automatic configurations
Automatic closure
enabling
Automation status
at switch-on
Reversal safety
operation
Activation of anti-
freeze system NIO
30-5 command
operation mode
30-3 command
operation mode
Radio receiver
operation
AUX1 board
operation
AUX2 board
operation
Start-up at maximum
power
Setting of step-by-step
sequence via command
30-5
Duration of STOP in
step-by-step sequence
via command 30-5
Standard settings
*
Automatic closing
time after partial
opening
Deceleration/braking
during closing
Deceleration distance on
opening
Automatic
closing time
Partial opening
measurement adjustment
Basic adjustments
Adjustment of thrust on
obstacles approaching
during opening
Adjustment of thrust on
obstacles approaching
during closing
Motor force adjustment
Adjustment of obstacle
recognition time at normal
speed
Adjustment of obstacle
recognition time during
deceleration
Start-up time adjustment
Adjustment of acceleration
time on closure
Deceleration/braking
during opening
Adjustment of acceleration
time on opening
*
Output 13 operating mode
Output G3 operating mode
Adjustment of thrust on
obstacles during opening
Deceleration distance on
closing
Adjustment of thrust on
obstacles during closing
NOTE: depending on the type of automation and operating mode, some menus may not
be available.
To Next Page
