1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
Pag. 16/58
12 Temperature probe NTC (external temperature) for dynamic setpoint / boiler / change over
13 Temperature probe NTC for combined defrost circuit #1
14 Temperature probe NTC for combined defrost circuit #2
15 Temperature probe NTC for auxiliary output #1
16 Temperature probe NTC for auxiliary output #2
17 Condenser probe circuit 1 ( temperature NTC / pressure 20 mA / ratio-metric 0÷ 5Volt )
18 Condenser probe circuit 2 ( temperature NTC / pressure 20 mA / ratio-metric 0÷ 5Volt )
19 Evaporator pressure probe circuit 1 (pressure 20 mA / ratio-metric 5Volt )
20 Evaporator pressure probe circuit 1 (pressure 20 mA / ratio-metric 5Volt )
21 Auxiliary output 1 pressure probe control (20 mA / ratio-metric 0÷ 5Volt).
22 Auxiliary output 2 pressure probe control (20 mA / ratio-metric 0÷ 5Volt).
23 Dynamic setpoint pressure probe (20 mA)
Every analogue input can be configured as digital input; after the number 18, the values o 1 c38
allow the configuration of the analogue input as digital inputs with the same meaning (o 1= remote
ON/OFF, o 2= Remote chiller / heat pump, …..).
8.3 DIGITAL INPUT CONFIGURATION ID1 ID18
Parameters involved:
CF24 = Configuration ID1…CF34 = Configuration ID18
0. Not enabled
1. Remote ON / OFF
2. Remote chiller / heat pump
3. Flow switch evaporator pump / supply fan overload
4. Flow switch condenser pump
5. Antifreeze heater circuit 1
6. Antifreeze heater circuit 2
7. High pressure switch circuit 1
8. High pressure switch circuit 2
9. Low pressure switch circuit 1
10. Low pressure switch circuit 2
11. Compressor 1 high pressure
12. Compressor 2 high pressure
13. Compressor 1 overload
14. Compressor 2 overload
15. Condenser fan overload of circuit 1
16. Condenser fan overload of circuit 2
17. Condenser fan overload of circuit 1 and 2 (common condenser)
18. Evaporator water pump overload
19. Support evaporator water pump overload
20. Condenser water pump overload
21. Support condenser water pump overload
22. End defrost of circuit 1
23. End defrost of circuit 2
24. Energy Saving
25. Pressure switch / compressor 1 oil
26. Pressure switch / compressor 2 oil
27. Pump down pressure switch of circuit 1
28. Pump down pressure switch of circuit 2
29. Generic alarm n°1
30. Generic alarm n°2
31. RTC disabled
32. Supplay fan enabled (the unit works only with the supplay fan)
