1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
Pag. 18/58
8.5 ANALOG OUTPUT CONFIGURATION 0 ÷ 10 VOLT (OUT1 E OUT2)
Parametri:
CF43 = Analog output OUT1 configuration
CF44 = Analog output OUT2 configuration
0 = output disabled
1 = 0..10V output for compressor 1 inverter controlled
2 = 0..10V output for compressor 2 inverter controlled
3 = 0..10V output for auxiliary output 1
4 = 0..10V output for auxiliary output 2
5 = 0..10V output for geothermal function
6 = 0..10V output for condenser fan circuit 1
7 = 0..10V output for condenser fan circuit 2
8 = 0..10V output for modulating evaporator pump
9 = 0..10V output for modulating condenser pump
o1..c26 = ON / OFF output for external relay management (same meaning of relays configuration)
8.6 CONFIGURAZIONE N° 2 USCITE ANALOGICHE 0 ÷ 10 VOLT / TAGLIO
DI FASE (OUT3 E OUT4)
Parametri:
CF45 = Configurazione uscita analogica n° 3
CF46 = Configurazione uscita analogica n° 4
0 = output disabled
1 = 0..10V output for compressor 1 inverter controlled
2 = 0..10V output for compressor 2 inverter controlled
3 = 0..10V output for auxiliary output 1
4 = 0..10V output for auxiliary output 2
5 = 0..10V output for geothermal function
6 = 0..10V output for condenser fan circuit 1
7 = 0..10V output for condenser fan circuit 2
8 = PWM output for condenser fan circuit 1
9 = PWM output for condenser fan circuit 2
o1..c26 = OFF output for external relay management (same meaning of relays configuration)
9 PROGRAMMING WITH THE “HOT KEY 64”
9.1 DOWNLOAD: HOW TO PROGRAM AN INSTRUMENT WITH A
PROGRAMMED “HOT KEY”
1. Turn off the instrument supply
2. Insert the hot key.
3. Turn on the power supply.
4. Immediately the parameters are downloaded.
During the download the regulation is locked and the top display shows the “doL” blinking label. At the
end of the download will appear:
