1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
Temperature to activate geothermal function 0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
Bar
Psi
Dec
int
Dec
int
US 23
Differential to deactivate geothermal function
0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
Bar
Psi
Dec
int
Dec
int
US 24
Time to activate/deactivate geothermal function
0 250 sec
US 25
Probe 1 selection (Pb1..Pb6) for geothermal function 0 6
US 26
Probe 2 selection (Pb1..Pb6) for geothermal function 0 6
US 27
Probes configuration for geothermal function
0= Probe 1 for geothermal function – probe 2 for geothermal function
1= Probe 2 for geothermal function – probe 1 for geothermal function
0 1
US 28
Geothermal function set point -50.0
-58
0
0
70.0
158
50.0
725
°C
°F
Bar
Psi
Dec
int
Dec
int
US 29
Geothermal function differential
0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
Bar
Psi
Dec
int
Dec
int
US 30
Direct / reverse action for geothermal function
0= direct action
1= reverse action
0 1
US 31
Minimum value for geothermal function 0 US32
Maximum value for geothermal function US31
100 %
Pr1
Password 0 999
Pr2
Password 0 999
Pr3
Password 0 999
Condenser fan
Param
eters
Description min max M. U. Resolu
tion
FA 1
Fan configuration output
0 = Not enabled
1 = Always on
2 = ON/OFF regulation with steps
3 = ON/OFF Continuous regulation
4 = Proportional speed control
0 4
FA 2
Fan operating mode
0= Dependent from the compressor
1= Independent from the compressor
0 1
FA 3
Operation time at maximun speed when the fans start 0 250 Sec
FA 4
Phase shifting of the fan motor
0 8
Micro
Sec
250µs
FA 5
Number of condensing circuits
0= one condenser circuit
1= two condenser circuits
0 1
FA 6
Pre-ventilation time before turning on the compressor in chiller mode 0 250 Sec
Fan in Chiller mode
FA 7
Minimum speed for condenser fan in Chiller mode.
To set the minimum fan speed percentage value (30..100%), it is
related to the fan power supply.
30 100 %
