dixell IC200CX Series User Manual

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
US 6
Probe selection for for auxiliary relay 2 control. Allows to select which
probe value Pb1..Pb6 controls the relay
1 6
US 7
Auxiliary relay 2 setpoint -50.0
-58
0.0
0
70.0
158
50.0
725
°C
°F
Bar
Psi
Dec
int
Dec
int
US 8
Auxiliary relay 2 differential 0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
Bar
Psi
Dec
int
Dec
int
Auxiliary proportional output n° 1
US 9
Auxiliary proportional output n° 1 operating mode
0= Not enabled
1= Always available with direct action
2= Available only when the unit is on with direct action
3= Always available with reverse action
4= Available only when the unit is on with reverse action
0 4
US 10
Probe selection for auxiliary proportional output 1
Allows to select which probe value Pb1..Pb6 controls output
1 6
US 11
Minimum value of the auxiliary proportional output 1
0 US12
%
US 12
Maximum value of the auxiliary proportional output 1
US11
100 %
US 13
Auxiliary proportional output 1 setpoint -50.0
-58
0.0
0
70.0
158
50.0
725
°C
°F
Bar
Psi
Dec
int
Dec
int
US 14
Auxiliary proportional output 1 differential 0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
Bar
Psi
Dec
int
Dec
int
Auxiliary proportional output n° 2
US 15
Auxiliary proportional output n° 2 operating mode
0= Not enabled
1= Always available with direct action
2= Available only when the unit is on with direct action
3= Always available with reverse action
4= Available only when the unit is on with reverse action
0 4
US 16
Probe selection for auxiliary proportional output 2
Allows to select which probe value Pb1..Pb10 controls output
1 6
US 17
Minimum value proportional output 2
0 US18
%
US 18
Maximum value proportional output 2
US17
100 %
US 19
Auxiliary setpoint proportional output 2 -50.0
-58
0.0
0
70.0
158
50.0
725
°C
°F
Bar
Psi
Dec
int
Dec
int
US 20
Differenzential proportional output 2 0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
Bar
Psi
Dec
int
Dec
int
Geothermal function
US 21
Geothermal function activation
0= only in chiller
1= only in heat pump
2= chiller and heat pump
0 2
