dixell IC200CX Series User Manual

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
WALL MOUNTING: use the vertical V-KIT (black, white and grey) as described in the following
scheme:
17 ELECTRICAL CONNECTIONS
The instrument is provided with:
• 2 removable terminal blocks MOLEX MICROFIT 14 and 18 ways for power supplay / digital and
analogue inputs and modulating outputs
• 1 removable terminal blocks AMP 12 ways for the relay outputs
• 5 ways connector for TTL RS485 interface outputs.
Wire size:

dixell IC200CX Series Specifications

General

Brand	dixell
Model	IC200CX Series
Category	Temperature Controller
Language	English
