• Leds 1 / 2 are blinking: the parameter can not be changed in Pr1 and Pr2 level.
• All the leds are off: the parameter is available only in Pr3.
• Led 4 on: the parameter can be changed also in Pr2.
• Led 4 blinking: the parameter is visible but not modifiable in Pr2.
• Leds 3 / 4 on: the parameter is visible and modifiable in Pr2 and in Pr1.
• Leds 3 / 4 blinking: the parameter is visible but not modifiable in Pr1 and in Pr2.
• The MENU key allows to exit from a family to reselect another without exit the Pr2 level.
• The MENU key allows to pass to Pr1 starting from a family label.
• To exit completely the programming push SET + UP.
11 FUNCTION MENU “ M” KEY
The function Menu is composed of the following items:
1) Show and reset the alarms ALrM
2) Compressor overload alarm reset COtr
3) Show and reset the alarm log ALOG
4) Upload the parameter into the Hot Key UPL
5) Enable – disable one or the two circuits CrEn
6) Enable – disable one of the compressors COEn
7) Enable – disable one of the pumps POEn
8) Display the compressor discharge temperature COdt
9) Show and reset the number of compressor running hour Hour
10) Show and reset the number of compressor starts-up COSn
11) Show the condensing fan speed percentage of the proportional output Cond
12) Show the percentage of the proportional output 0 ÷ 10 Vdc Pout
13) Time counting to next defrost cycle, under heat pump mode, dF
14) Show the probe temperatures that enabled to control the auxiliary output uS
15) Show the probe the temperature of the remote panels trEM
MENU FUNCTION ACCESS: Push and release the M key.
11.1 ALARM LIST: SHOW AND RESET
ALrM FUNCTION
Enter the function MENU pushing M key one time
1) Use the UP or DOWN to select the AlrM label
2) Push SET key (Nothing happens if there are no active alarm events)
