dixell IC200CX Series User Manual

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
CO 83
Probe selection (Pb1..Pb6) for modulating condenser water pump in
chiller
0 6
CO 84
Probe selection (Pb1..Pb6) for modulating condenser water pump in
heat pump
0 6
CO 85
Set point for modulating condenser water pump in chiller -50.0
-58
0
0
70.0
158
50.0
725
°C
Int
Dec
int
CO 86
Proportional band for modulating condenser water pump in chiller 0.1
1
0.1
1
25.0
45
14.0
203
°C
Int
Dec
int
CO 87
Set point for modulating condenser water pump in heat pump -50.0
-58
0
0
70.0
158
50.0
725
°C
Int
Dec
int
CO 88
Proportional band for modulating condenser water pump in heat
pump
0.1
1
0.1
1
25.0
45
14.0
203
°C
Int
Dec
int
CO 89
Minimun value of the signal for the modulation of the pump 0 CO90
%
CO 90
Maximun value of the signal for the modulation of the pump CO89
100 %
CO 91
Time at maximum speed when the pump is activated 0 250 sec
CO 92
Value of the signal when the compressor is OFF or when the unit is in
STD-BY or remote OFF
0 100 %
CO 93
Time at maximum speed during the switching off of the pump 0 250 sec
Pr1
Password 0 999
Pr2
Password 0 999
Pr3
Password 0 999
Auxiliary relay
Param
eters
Description min max M. U. Resolu
tion
Auxiliary relay of the circuit 1
US 1
Auxiliary relay 1 operating mode
0= Not enabled
1= Always available with direct action
2= Available only when the unit is on with direct action
3= Always available with reverse action
4= Available only when the unit is on with reverse action
0 4
US 2
Probe selection for auxiliary relay 1 control. Allows to select which
probe Pb1..Pb6 controls the relay
1 6
US 3
Auxiliary relay 1 setpoint -50.0
-58
0.0
0
70.0
158
50.0
725
°C
°F
Bar
Psi
Dec
int
Dec
int
US 4
Auxiliary relay 1 differential 0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
Bar
Psi
Dec
int
Dec
int
Auxiliary relay circuit 2
US 5
Auxiliary relay 2 operating mode
0= Not enabled
1= Always available with direct action
2= Available only when the unit is on with direct action
3= Always available with reverse action
4= Available only when the unit is on with reverse action
0 4
