1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
Pressure value at 4mA or 0.5 Vdc of the PB4 transducer 0
-14
50.0
725
Bar
psi
Dec
int
CF 23
Pressure value at 20mA or 5 Vdc of the PB4 transducer 0
-14
50.0
725
Bar
psi
Dec
int
Digital Inputs
CF 24
Configuration of ID1 0 C38
CF 25
Configuration of ID2 0 C38
CF 26
Configuration of ID3 0 C38
CF 27
Configuration of ID4 0 C38
CF 28
Configuration of ID5 0 C38
CF 29
Configuration of ID6 0 C38
CF 30
Configuration of ID7 0 C38
CF 31
Configuration of ID8 0 C38
CF 32
Configuration of ID9 0 C38
CF 33
Configuration of ID10 0 C38
CF 34
Configuration of ID11 0 C38
Relay Outputs
CF 35
Configuration of RL1 0 C36
CF 36
Configuration of RL2 0 C36
CF 37
Configuration of RL3 0 C36
CF 38
Configuration of RL4 0 C36
CF 39
Configuration of RL5 0 C36
CF 40
Configuration of RL6 0 C36
CF 41
Configuration of RL7 0 C36
CF 42
Configuration of RL8 0 C36
Proportional output
CF 43
OUT 1 configuration
0= Not enabled
1= 0..10V signal for compressor 1 inverter controlled
2= 0..10V signal for compressor 2 inverter controlled
3= 0..10V signal for auxiliary output 1
4= 0..10V signal for auxiliary output 1
5= 0..10V signal for geothermal function
6= 0..10V signal for condenser fan circuit 1
7= 0..10V signal for condenser fan circuit 2
8= 0..10V signal for modulating evaporator pump
9= 0..10V signal for modulating condenser pump
o1 .. c26 signal to drive external relay
0
o 1
9
c26
CF 44
OUT 2 configuration
0= Not enabled
1= 0..10V signal for compressor 1 inverter controlled
2= 0..10V signal for compressor 2 inverter controlled
3= 0..10V signal for auxiliary output 1
4= 0..10V signal for auxiliary output 1
5= 0..10V signal for geothermal function
6= 0..10V signal for condenser fan circuit 1
7= 0..10V signal for condenser fan circuit 2
8= 0..10V signal for modulating evaporator pump
9= 0..10V signal for modulating condenser pump
o1 .. c26 signal to drive external relay
0
o 1
9
c26
