1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
AL 4
Low pressure alarm differential from analogue input 0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
bar
psi
Dec
int
Dec
Int
AL 5
Maximum number of low pressure events from digital/analogue
inputs:
Always manual reset if AL05 = 0
Always automatic reset if AL05 =16
From automatic to manual reset if AL05= 1..15
0 16
AL 6
Low temperature/pressure alarm during defrost
0= Not enabled
1= Enabled
0 1
AL 7
Low temperature/pressure alarm delay during defrost 0 250 Sec
AL 8
Low temperature/pressure alarm with unit in OFF or stand – by:
0 = Not enabled
1= Alarm enabled
0 1
High Alarm
AL 9
High temperature/pressure alarm from analogue input -50.0
-58
0.0
0
70.0
158
50.0
725
°C
°F
bar
psi
Dec
int
Dec
int
AL 10
High temperature/pressure alarm differential from analogue input 0.1
1
0.0
0
25.0
45
14.0
203
°C
°F
bar
psi
Dec
int
Dec
int
Oil Alarm
AL 11
Low oil pressure / level delay from digital input 0 250 Sec
AL 12
Minimum time for low oil pressure / level from digital input activation in
normal working condition.
0 250 Sec
AL 13
Maximum number of low oil pressure/level events:
Always manual reset if AL13= 0
Always automatic reset if AL13 =16
From automatic to manual reset if AL13 = 1..15
0 16
AL 14
Low oil pressure / oil level when the compressor is OFF
0= alarm disabled
1= alarm enabled
0 1
Condenser Flow alarm
AL 15
Condenser water flow configuration
0= Not enabled
1= Enabled only in chiller mode
2= Enabled only in heat pump mode
3= Enabled in chiller and heat pump mode
0 3
AL 16
Condenser flow switch delay after pump activation 0 250 Sec
AL 17
Flow switch activation time to generate the manual condenser flow
alarm
0 250 Sec
AL 18
Flow switch activation time to generate the automatic condenser flow
alarm
0 250 Sec
AL 19
Flow switch deactivation time to reset the condenser flow alarm 0 250 Sec
Evaporator Flow alarm
AL 20
“Evaporator flow switch / supply fan overload” delay after pump
activation
0 250 Sec
AL 21
Flow switch activation time to generate the manual evaporator flow
alarm
0 250 Sec
AL 22
“Evaporator flow switch / supply fan overload” activation time to
generate the automatic alarm
0 250 Sec
