1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
AL 38
Probe selection for antifreeze alarm in chiller mode
0= disabled
1= evaporator inlet temperature
2= evaporator 1 / 2 outlet temperature
3= evaporator 1 / 2 outlet temperature and common outlet
temperature
4= external air temperature
0 4
AL 39
Probe selection for condenser antifreeze alarm
0= disabled
1= condenser common inlet temperature
2= condenser 1 / 2 inlet temperature and common inlet temperature
3= condenser 1 / 2 outlet temperature
4= condenser 1 / 2 outlet temperature and common outlet
temperature
0 4
Anti-freeze alarm in Heat pump mode
AL 40
Minimum limit of the setpoint in heat pump mode -50.0
-58
AL39
°C
°F
Dec
int
AL 41
Maximum limit of the setpoint in heat pump mode
AL38
70.0
158
°C
°F
Dec
int
AL 42
Anti-freeze alarm setpoint in heat pump
Setpoint temperature for low anti-freeze alarm, low ambient
temperature (air/air), low temperature air outlet (air/air)
AL31 AL32 °C/°F Dec/int
AL 43
Differential of anti freeze alarm in heat pump mode. To reset the anti-
freeze, low ambient Temperature (air/air), low temperature air outlet
(air/air) alarms.
0.1
1
25.0
45
°C
°F
Dec
int
AL 44
Antifreeze alarm delay (low outlet temperature for air/air unit) at the
stert up in heat pump mode
0 250 Sec
AL 45
Anti-freeze alarm delay for low air ambient temperature or low outlet
air temperature in heat pump normal condition.
0 250 Sec
AL 46
Maximum number of anti-freeze alarm events for low air ambient
temperature or low outlet air temperature in heat pump. It sets the
alarm reset condition:
Always manual reset AL46 = 0
Always automatic reset AL46 = 16
From automatic to manual reset if AL46 = 1..15
0 16
AL 47
Anti-freeze alarm configuration in heat pump
0= to turn the compressors off when the anti-freeze control probe is
lower than AL33 (after the time delay), the display shows the alarm
label.
Buzzer and Alarm relay are not activated.
1= to turn the compressors off when the anti-freeze control probe is
lower than AL33 (after the time delay), the display shows the alarm
label.
Buzzer and Alarm relay are activated.
0 1
AL 48
Probe selection for antifreeze alarm in heat pump mode
0= disabled
1= evaporator inlet temperature
2= evaporator 1 / 2 outlet temperature
3= evaporator 1 / 2 outlet temperature and common outlet
temperature
4= external air temperature
0 4
Compressor high discharge temperature
AL 49
Compressor high discharge temperature setpoint
0
0
150
302
°C
°F
Dec /
int
int
AL 50
Compressor high discharge temperature differential 0
0
25.0
45
°C
°F
Dec
int
