Page 70
Machine Front View
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
1a W307 Door Assembly, Glass
1b 800,101,860.01 Pike Door Assy., Glass
2 W058 Gasket, Glass Door
3 W327 Top Hinge, Glass Door
4 W334 Top Hinge, Service Door
5a F240-2 Catch, 3-Point Lock Top
5b F240-6 Catch, 3-Point Lock Bottom
6 W296 Strike, Door Lock 3 Point
7 W945 Reflective Tape - 3 Square
8 W025-1 Leg Assembly, Steel, Formed 2 per
cabinet 3
rd
version
9 D048 Leg Leveler, ½-20, 2.88LG
10 W411 Plate, Mounting Leg
11 W970 Leveler, Black, 6/6 Nylon
12 W025 Leg Assembly, Steel, Formed 2
nd
version
13 W336 Round Leg Assembly, 5/8-11 Stud 1
st
version
14 W337 Bottom Hinge, Service Door
15 804,913,760.01 Assy. Product Sensor w/ Harness
16 W326 Bottom Hinge, Glass Door
17 W777 Sensor, Photoelectric (s/n's 0001 to 1617 only)
18 W443 Assy. Pad, Recovery Unit
19 W024 Door Assembly, Recovery Unit (W332)
D124 Door Assembly, Recovery Unit (D332)
20 W332 Assy. Recovery Unit, Standard, 6 Tray
801,810,910.01 Assy. Recovery Unit, Tall, 5 Tray 20 oz.
21 W363 Deflector, Bottle Drop Plastic Wedge
22 622,050,900.03 Sensor Mounting Plate
23 W990 Filter 10x20x1
Part numbers subject to change without notice.
