Page 72
Cabinet Detail
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
1 622,070,020.03 Left Tray Mounting Bracket, 20 oz.
D071-1 Left Tray Mounting Bracket, 6 Tray
2 D042 Rear Tray Support Bracket, 20 oz.
D070 Rear Tray Support Bracket, 6 Tray
3 622,060,060.13 Security Angle Hinge, Left
4 622,060,040.13 Security Trim, Top
5a 804,100,770.21 Switch, Door
5b 622,060,050.03 Door Switch Bracket
6a 801,903,560.01 Rear Plate
6b W417 Grille, Rear
7 622,020,080.03 Brace, Rear Base Plate
8a 622,041,100.13 Fan Assy., Evaporator (115V 60 Hz 9W)
8b 622,041,000.13 Fan Assy., Evaporator (230V 50 Hz 9W)
9 622,060,070.13 Security Angle Hinge Right
10 622,050,100.03 Cash Box Assy.
11 D042 Rear Tray Support Bracket, 20 oz.
D070 Rear Tray Support Bracket, 6 Tray
12 622,070,030.03 Right Tray Mounting Bracket, 20 oz.
D071-2 Right Tray Mounting Bracket, 6 Tray
13 622,050,070.03 Coin Box Holder
14 622,050,000.03 Cash Box Shelf
15 D200-3 Locking Cash Box Kit (used w/ metal cash box)
not shown 622,060,200.03 Lamp Holder Assy. (includes base & harness)
not shown W486 Assy. Ballast 110V/60 Hz.
not shown W153 Assy. Ballast 220V/50 Hz.
not shown W351 Lens, Lamp Assy.
not shown W845 Lamp Fluorescent 40W 48"
not shown 622,041,200.03 Evaporator Drain Pan Assy.
Part numbers subject to change without notice.
