Page 76
Refrigeration Unit – Tecumseh (2145 – In Line Condenser)
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
1 D029 Condenser Fan Assy., 115VAC (Hidden)
D029-1 Condenser Fan Assy., 230VAC (Hidden)
F470 Condenser Fan Motor, 115VAC/60 Hz, 9W
F471 Condenser Fan Motor, 230VAC/50 Hz 9W
F469 Condenser Fan Blade, FV800CW30S
2 W291 Compressor, 115VAC/60 Hz
W290 Compressor, 220VAC/50 Hz
3 D609-1 Start Relay, 110VAC, Tecumseh
D609-2 Start Relay, 220VAC, Tecumseh
4 D610-1 Start Capacitor, 110VAC, Tecumseh
D610-2 Start Capacitor, 220VAC, Tecumseh
5 802,600,630.01 Evaporator
6 W097 Condenser, Tecumseh In-Line
7 D608-1 Thermal Overload, 110VAC, Tecumseh
D608-2 Thermal Overload 220VAC, Tecumseh
Part numbers subject to change without notice.
