Page 78
Refrigeration Unit – Tecumseh (2145 – Roll Up Condenser)
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
1 D029 Condenser Fan Assy., 115VAC (Hidden)
D029-1 Condenser Fan Assy., 230VAC (Hidden)
F470 Condenser Fan Motor, 115VAC/60 Hz 9W
F471 Condenser Fan Motor, 230VAC/50 Hz 9W
F469 Condenser Fan Blade 8" 30
0
F
2 W291 Compressor, 115VAC/60 Hz
W290 Compressor, 220VAC/50 Hz
3 D609-1 Start Relay, 110VAC - Tecumseh
D609-2 Start Relay, 220VAC - Tecumseh
4 D610-1 Start Capacitor, 110VAC - Tecumseh
D610-2 Start Capacitor, 220VAC - Tecumseh
5 802,600,630.01 Evaporator
6 802,600,620.01 Condenser - Roll Up
7 D608-1 Thermal Overload, 110VAC - Tecumseh
D608-2 Thermal Overload 220VAC - Tecumseh
8A 622,040,200.03 Refrigeration Unit w/ Roll Up Condenser
115VAC 1600C-T
8B 622,041,600.03 Refrigeration Unit w/ Roll Up Condenser
110VAC 1600 C-A
F235-3 Drain Pan
622,040,120.03 Drain Pan 1600 C-A
Part numbers subject to change without notice.
