Page 80
Service Door (Front)
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
ASSY 622,050,500.03 Service Door Assembly, 3 Point Lock
W308-SP Service Door Assembly, Single Point Lock
622,051,800.03 Service Door Assy. Double Knockout, 3 Point Lock
1 W383 Bezel, Coin Return
2 801,810,520.01 Bezel, Service Door - Domestic
3 W013 Assy. Coin Return Lever
4 801,518,060.01 T-Handle Assy.
5 W453-2 Button Array Keypad, Rubber
6 W453-1 Keypad, Membrane Switch
7 W367 Display Filter, Red
8 W737 Bearing, Service Door
9 W481 Assembly, 8 Digit, 14 Segment Display
10 W121 Cover, Display
11 W333 Slide, Coin
12 F327 Cotter Pin
13 W329 Cam, Coin Return
14 622,051,200.13 Assy., Coin Return Cup
15 622,050,140.03 Coin Return Door Flap
16 W385 Assembly, Coin Guide
17 622,051,400.03 Weld Assy., Service Door (3 Point Lock)
W164-SP Service Door (Single Point Lock)
622,050,240.03 Service Door (3 Point Lock w/ 2 knockouts)
18 D114 Keypad Cable Clamp Kit
19A 360,050,720.73 Validator Filler Plate (All DN built doors)
19B F283 Validator Filler Plate (All ECC built doors)
20 902,001,020.11 Gasket Validator Filler Plate (All DN built doors)
Part numbers subject to change without notice.
