Appendix A XT30/XT50 User Guide 51
Supervisory Event Displays Wireless Jamming Event Displays
This displays wireless interference events that have occurred.
Keypad Display Description
The DMP wireless receiver detected
interference on October 17 at
11:41 AM.
Wireless Jamming Event Types - There are three event types:
TBL - Trouble (an interference event occurred when the panel
was disarmed)
ALR - Alarm (an interference event occurred when any area
was armed)
RST - Restore
Wireless Trouble Event Displays
This displays events when the wireless receiver was not
communicating with the panel.
Keypad Display Description
TBL 11:41A 10/17
WIRELESS
A DMP wireless receiver trouble
occurred on October 17 at 11:41
AM.
Wireless Trouble Event Types - There are two event types:
TBL - Trouble RST - Restore
ALR 11:41A 10/17
WIRELESS
This displays the automatic test report date and time.
Description
MSG 11:58P 10/17
AUTO RECALL
The test report was sent to the
central station at the date and time
shown.
System Monitor Event Displays
This displays any problems with the system AC power or battery.
Description
TBL 11:41A 10/17
AC POWER
An AC failure occurred at 11:41 AM
on October 17.
System Monitor Event Types - There are two event types:
TBL - Trouble RST - Restore
System Monitor Event Names - There are two system monitors:
AC POWER BATTERY
