Appendix B
1100 Series Wireless Description
If your system uses wireless devices and includes key fob(s), refer
to the following information. The wireless section includes a
brief discussion of key fob(s) and a drawing identifying the key
fob buttons. Refer to the System Setup section of this guide to
check the button programming list for key fob(s) connected to your
system.
For best operation, allow the LED to turn on and then turn off
before pressing another button. The key fob may not complete
sending the signal for the button press if another button is pressed
too soon.
LED Status Operation
Depending on the programmed action of a key fob button, the
Status LED lights to acknowledge a button press or to indicate the
armed state of the system.
• When the button is programmed for Panic, Panic 2,
Emergency, Emergency 2, Output, or Sensor Reset, a 1/2
second Green light displays to acknowledge the button
press.
• When the button is programmed for Arm, Disarm, Toggle
(Arm/Disarm), or Status, the system armed status is
received by the key fob and the LED lights once as shown in
the table below.
LED Color Duration Description
Red 2.0 Seconds All System On
Green 2.0 Seconds All System Off
Green/Red 2.0 Seconds
System On
(Some Areas Armed)
When a button is pressed that is not programmed, the LED does
not operate.
