Dodge Ram 2004 - Page 182

TEST ACTION APPLICABILITY
2 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
Disconnect the Right Curtain Airbag connector.
NOTE: Check connectors - Clean repair as necessary.
WARNING: TO AVOID PERSONAL INJURY OR DEATH, DO NOT PLACE AN
INTACT UNDEPLOYED CURTAIN AIRBAG FACE DOWN ON A HARD SUR-
FACE, THE AIRBAG WILL PROPEL INTO THE AIR IF ACCIDENTALLY
DEPLOYED.
Connect the appropriate Load Tool to the Right Curtain Airbag connector.
WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN IGNITION
ON, THEN RECONNECT THE BATTERY.
With the DRBIIIt, read active Airbag Control Module DTC’s.
Does the DRBIIIt show RIGHT CURTAIN SQUIB 1 CIRCUIT SHORT?
All
Yes → Go To 3
No → Replace Right Curtain Airbag in accordance with the Service
Information.
Perform __AIRBAG VERIFICATION TEST - VER 1.
3 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
Disconnect the Load Tool from the Right Curtain Airbag connector(s).
Disconnect the Airbag Control Module connector(s).
NOTE: Check connectors - Clean and repair as necessary.
WARNING: TO AVOID PERSONAL INJURY OR DEATH, DO NOT PLACE AN
INTACT UNDEPLOYED CURTAIN AIRBAG FACE DOWN ON A HARD SUR-
FACE, THE AIRBAG WILL PROPEL INTO THE AIR IF ACCIDENTALLY
DEPLOYED.
Connect the appropriate Load Tool ACM Adaptor to the ACM connector(s).
Measure the resistance between the Right Curtain Squib 1 Line 1 and Line 2 circuits
at the Right Curtain Airbag connector(s).
Is the resistance below 10K ohms?
All
Yes → Repair Right Curtain Squib 1 Line 1 short to Line 2 circuit.
Perform __AIRBAG VERIFICATION TEST - VER 1.
No → Go To 4
4 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
WARNING: IF THE AIRBAG CONTROL MODULE IS DROPPED AT ANY
TIME, IT MUST BE REPLACED. FAILURE TO TAKE THE PROPER PRE-
CAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT
AND PERSONAL INJURY OR DEATH.
If there are no possible causes remaining, view repair.
All
Repair:
Replace the Airbag Control Module in accordance with Service
Information.
Perform __AIRBAG VERIFICATION TEST - VER 1.
168
AIRBAG
RIGHT CURTAIN SQUIB 1 CIRCUIT SHORT — Continued
