Symptom:
FCM-WIPER SPEED RELAY OUTPUT CIRCUIT HIGH
POSSIBLE CAUSES
INTERMITTENT CONDITION
WIPER HIGH/LOW RELAY
POWER DISTRIBUTION CENTER INTERNAL SHORT TO VOLTAGE
FRONT CONTROL MODULE
TEST ACTION APPLICABILITY
1 Turn the ignition on.
With the DRBIIIt, clear all FCM DTC’s.
Actuate the Wipers in all speed positions.
With the DRBIIIt, read the DTC information.
Does the DRBIIIt read: Wiper Speed Relay Output Circuit High?
All
Yes → Go To 2
No → The condition that caused the symptom is currently not present.
Inspect the related wiring for a possible intermittent condition.
Look for any chafed, pierced, pinched, or partially broken wires.
Perform BODY VERIFICATION TEST - VER 1.
2 Turn the ignition off.
Remove the Wiper High/Low Relay from the IPM.
Turn the ignition on.
Activate the Wiper Switch to all speed positions.
With the DRBIIIt, read DTCs.
Does the DRBIIIt display: Wiper Speed Relay Output Circuit Open?
All
Yes → Replace the Wiper High/Low Relayin accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 3
3 Turn the ignition off.
Remove the Wiper High/Low Relay from the IPM.
Remove the FCM from the IPM.
Measure the voltage between the Wiper High/Low Relay Control circuit and ground
in the IPM.
Is there any voltage present?
All
Yes → Replace the Power Distribution Center (PDC) in accordance with
the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Front Control Module (FCM) in accordance with the
Service Information.
Perform BODY VERIFICATION TEST - VER 1.
541
WINDSHIELD WIPER & WASHER
