Dodge Ram 2004 - Fog Lamp Relay; Horn Relay; Wiper High;Low Relay; Park Lamp Relay

FOG LAMP RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 INTERNAL FUSED B(+)
86 INTERNAL FOG LAMP RELAY CONTROL
87 L89 18WT/YL FOG LAMP RELAY OUTPUT
87A - -
HORN RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 INTERNAL FUSED B(+)
86 INTERNAL HORN RELAY CONTROL
87 X2 18DG/OR HORN RELAY OUTPUT
87A - -
WIPER HIGH/LOW RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL WIPER CONTROL
85 INTERNAL WIPER HIGH/LOW RELAY CONTROL
86 INTERNAL FUSED B(+)
87 W4 16BR/OR WIPER RELAY HIGH SPEED OUTPUT
87A W3 16BR/WT WIPER RELAY LOW SPEED OUTPUT
PARK LAMP RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 INTERNAL FUSED B(+)
86 INTERNAL PARK LAMP RELAY CONTROL
87 INTERNAL PARK LAMP RELAY OUTPUT
87A - -
TRAILER TOW LEFT TURN RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 INTERNAL FUSED B(+)
86 INTERNAL TRAILER TOW LEFT TURN RELAY CONTROL
87 L673 18YL TRAILER TOW LEFT TURN RELAY OUTPUT
87A - -
TRAILER TOW RIGHT TURN RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 INTERNAL FUSED B(+)
86 INTERNAL TRAILER TOW RIGHT TURN RELAY CONTROL
87 L674 18LG TRAILER TOW RIGHT TURN RELAY OUTPUT
87A - -
WIPER ON/OFF RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL WIPER CONTROL
85 INTERNAL WIPER ON/OFF RELAY CONTROL
86 INTERNAL FUSED B(+)
87 INTERNAL FUSED B(+)
87A Z920 12BK GROUND
C
O
N
N
E
C
T
O
R
P
I
N
O
U
T
S
590
CONNECTOR PINOUTS
