Symptom:
LEFT CURTAIN SQUIB 1 SHORT TO GROUND
When Monitored and Set Condition:
LEFT CURTAIN SQUIB 1 SHORT TO GROUND
When Monitored: With the ignition on, the ACM monitors the resistance of the Left
Curtain Squib 1 circuits.
Set Condition: When the ACM detects a short to ground in either Left Curtain Squib 1
circuits.
POSSIBLE CAUSES
LEFT CURTAIN SQUIB 1 SHORT TO GROUND
LEFT CURTAIN SQUIB 1 LINE 1 OR LINE 2 SHORTED TO GROUND
ACM, LEFT CURTAIN SQUIB 1 SHORT TO GROUND
STORED CODE OR INTERMITTENT CONDITION
ACTIVE CODE PRESENT
TEST ACTION APPLICABILITY
1 Turn the ignition on.
NOTE: Ensure that the battery is fully charged.
NOTE: For the purpose of this test, the AECM and ORC modules will be
referred to as an ACM.
SELECT ACTIVE or STORED DTC:
All
ACM - ACTIVE DTC
Go To 2
ACM - STORED DTC
Go To 5
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
77
AIRBAG
