Dodge Ram 2004 - Left Front I;P and Right Rear Channels Short Across

Symptom:
LEFT FRONT I/P AND RIGHT REAR CHANNELS SHORT ACROSS
When Monitored and Set Condition:
LEFT FRONT I/P AND RIGHT REAR CHANNELS SHORT ACROSS
When Monitored: When the DRBIIIt performs the Speaker Output test.
Set Condition: When the Left Front I/P Speaker and Right Rear Speaker circuits are
simultaneously shorted.
POSSIBLE CAUSES
LEFT FRONT I/P AND RIGHT REAR CHANNELS SHORTED ACROSS
LEFT FRONT I/P AND RIGHT REAR SPEAKER CIRCUITS SHORTED
AMPLIFIER
TEST ACTION APPLICABILITY
1 NOTE: The fault condition must be present to continue diagnosis. Use the
DRBIIIt to perform the Amplifier pretest to verify the fault condition is
present before continuing diagnosis.
NOTE: Amplifier speaker circuits are both shorted simultaneously.
Turn the ignition off.
Access and disconnectthe Left Front I/Pand RightRear Speaker harnessconnectors.
Turn the ignition on.
With the DRBIIIt, perform the Amplifier pretest.
Is the fault condition still present?
All
Yes → Go To 2
No → Replace the Left Front I/Pand Right Rear Speakers inaccordance
with the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
2 Turn the ignition off.
Access and disconnect the Left Front I/P Speaker harness connector.
Access and disconnect the Right Rear Speaker harness connector.
Access and disconnect the Amplifier C2 harness connector.
Measure the resistance of the Left Front I/P Speaker (+) and (-) circuits.
Measure the resistance of the Right Rear Speaker (+) and (-) circuits.
Is the resistance below 5.0 ohms on each measurement?
All
Yes → Repair both Speaker (+) and (-) circuits for a short together.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace theAmplifier inaccordance with the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
212
AUDIO
