Symptom:
*SEAT BELT WARNING INDICATOR ALWAYS OFF - STANDARD
CAB
POSSIBLE CAUSES
SEAT BELT SWITCH SENSE CIRCUIT SHORT TO GROUND
INSTRUMENT CLUSTER
TEST ACTION APPLICABILITY
1 Turn the ignition off.
Disconnect the Seat Belt Switch harness connector.
Disconnect the Instrument Cluster C1 harness connector.
Measure the resistance between ground and the seat Belt Switch Sense circuit.
Is the resistance below 5.0 ohms?
All
Yes → Repair the Seat Belt Switch Sense circuit for a short to ground.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace and configure the Instrument Cluster in accordance with
the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
453
INSTRUMENT CLUSTER
