TEST ACTION APPLICABILITY
6 Turn the ignition off.
Disconnect the Clockspring C1 harness connector.
Turn the ignition on.
With the DRB, enter Instrument Cluster then Sensors and monitor the Remote Radio
SW voltage.
Is the voltage above 3.2 volts?
All
Yes → Replace the Clockspring in accordance with the service informa-
tion.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 7
7 Turn the ignition off.
Disconnect the Clockspring C1 harness connector.
Disconnect the Instrument Cluster harness connectors.
Measure the resistance between ground and the Radio Control MUX circuit.
Is the resistance below 5.0 ohms?
All
Yes → Repair the Radio Control MUX circuit for a short to ground
between the clockspring and the Instrument Cluster.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Instrument Cluster in accordance with the service
information.
Perform BODY VERIFICATION TEST - VER 1.
234
AUDIO
REMOTE RADIO SWITCH CIRCUIT STUCK — Continued
To Next Page
