TEST ACTION APPLICABILITY
4 Turn the ignition off.
Disconnect the FCM harness connector.
Disconnect the Washer Fluid Level Switch harness connector.
Measure the resistance between ground and the Washer Fluid Level Switch Signal
circuit.
Is the resistance below 5.0 ohms?
All
Yes → Repair the Washer Fluid Level Switch Signal circuit for a short to
ground.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Front Control Module (FCM) in accordance with the
Service Information.
Perform BODY VERIFICATION TEST - VER 1.
531
WINDSHIELD WIPER & WASHER
FCM-WASHER FLUID LEVEL SENSOR CIRCUIT FAILURE — Continued
