TEST ACTION APPLICABILITY
3 Turn the ignition off.
Disconnect the Instrument Cluster C2 harness connector.
Disconnect the Multi- Function Switch harness connector.
Measure the resistance between ground and the Wash/beam Select Switch Feed
circuit.
Is the resistance below 5.0 ohms?
All
Yes → Repair the Wash/Beam Select Switch Feed circuit for a short to
ground.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace and configure the Instrument Cluster in accordance with
the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
545
WINDSHIELD WIPER & WASHER
MIC-WASH-BEAM INPUT CIRCUIT SHORTED — Continued
