TEST ACTION APPLICABILITY
2 WARNING: TO AVOID PERSONAL INJURY OR DEATH,TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
Disconnect the Driver Airbag connector(s).
WARNING: DO NOT PLACE AN INTACT UNDEPLOYED AIRBAG FACE
DOWN ON A HARD SURFACE, THE AIRBAG WILL PROPEL INTO THE AIR
IF ACCIDENTALLY DEPLOYED. FAILURE TO TAKE THE PROPER PRE-
CAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT
AND PERSONAL INJURY OR DEATH.
NOTE: Check connectors - Clean and repair as necessary.
Connect the appropriate Load Tool to the Driver Airbag connector(s).
WARNING: TO AVOID PERSONAL INJURY OR DEATH,TURN THE IGNI-
TION ON, THEN RECONNECT THE BATTERY.
With the DRBIIIt, read the active Airbag Control Module DTC’s.
Does the DRBIIIt show DRIVER SQUIB 2 SHORT TO BATTERY?
All
Yes → Go To 3
No → Replace the Driver Airbag in accordance with the Service Infor-
mation.
Perform __AIRBAG VERIFICATION TEST - VER 1.
3 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
Disconnect the Load Tool from the Driver Airbag connector(s).
Disconnect the Clockspring connector(s).
NOTE: Check connectors - Clean and repair as necessary.
Connect the appropriate Load Tool to the Clockspring connector(s).
WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION ON, THEN RECONNECT THE BATTERY.
With the DRBIIIt, read the active Airbag Control Module DTC’s.
Does the DRB show DRIVER SQUIB 2 SHORT TO BATTERY ?
All
Yes → Go To 4
No → Replace the Clockspring in accordance with the Service Informa-
tion.
Perform __AIRBAG VERIFICATION TEST - VER 1.
4 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
Disconnect the Load Tool from the Clockspring connector(s).
Disconnect the Airbag Control Module connector(s).
NOTE: Check connectors - Clean and repair as necessary.
Connect the appropriate Load Tool Adaptor to the Airbag Control Module connec-
tor(s).
WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION ON, THEN RECONNECT THE BATTERY.
Measure the voltage on the Driver Squib 2 Line 1 and Line 2 from the Clockspring
connector to ground.
Is there any voltage present?
All
Yes → Repair the Driver Squib 2 Line 1 or Line 2 circuits shorted to
battery.
Perform __AIRBAG VERIFICATION TEST - VER 1.
No → Go To 5
63
AIRBAG
DRIVER SQUIB 2 SHORT TO BATTERY — Continued
