MAINTENANCE AND FAULT FINDING
5-10 L025317 Issue 1 March 2011
579 Printer enabling.. The laser is switched
on but warming up.
Wait for the printer to be
ready.
580 Inconsistent Laser
On State
The laser start input
level is being
overridden by a user
interface laser on
selection or by a fault
message.
In "Install Options" the option
"Laser On level sensitive
(hardware)" has been selected.
This means that if the external
laser start input is set to high
the printer enables or is
enabled, if the input is set to
low the printer is not enabled.
However due to fault
conditions or manual user
interaction the input status can
differ from the mark enable
status - in that case this
warning is displayed and the
'external laser start' signal
should be set to low.
581 Next controller
not ready
The next controller
in a "chain" in a
Multihead
configuration is not
ready.
Check readiness of the next
controller down the "chain".
582 Controller Idle
(Multi Head
System)
The system is part of
a multi head "chain"
but has been disabled
(see install options).
This is for
information only.
If this controller needs to work
enable it in the install options
of the user interface.
583 External Interlock
has been opened
One or both
interlocks was opened
but is now closed.
If the guards were not opened
check for a bad connection on
the interlock.
594 Safety Relay Fault There was a laser start
command present
while one or both
(CAT3/4) interlocks
where not closed.
Make sure the interlocks are
closed before giving the laser
start input.
600 Irregular Laser
Off Procedure
The laser did not stop
when the DSP
expected it to.
Contact Domino
601 Laser Off Delay
Ends During
Laser On Delay
Laser parameter
misconfiguration in
message.
Contact Domino
Status Message Cause Suggested Action
